Ducted air conditioners

Residential / Commercial

Ducted

The Mono Split ducted models have a slim design and high head adjustable up to 160 Pa.

A height of just 245 mm ensures viable and easy installation in low ceilings.

The high head perfectly distributes air flow to condition a large environment by means of only one indoor unit (assuming an appropriate distribution of ducts).

Find a Dealer

Download Area

Characteristics

Models: 12.000, 18.000, 24.000, 36.000, 48.000, 60.000
Slim design (245 mm height)
High head up to 160Pa
Complete range from 3,5 to 16 kW (from 12.000 to 60.000 Btu/h)
High energy efficiency class: A++ in cooling and class A+ in heating
Eco-friendly R32 refrigerant and greater performance
Silent operation
Extended operating limits (operation from -15 °C to +52 °C)
Flush-mounted touch screen control supplied as standard
Auto restart after a voltage drop
Condensate drainage supplied as standard
Optional remote control

Features

Heating and cooling

A year-round comfort: you can heat your home in winter and cool it in summer, with one sole product

Technical Specification

MODELS		12.000 Btu/h	18.000 Btu/h	24.000 Btu/h	36.000 Btu/h	48.000 Btu/h	60.000 Btu/h
Erp Data
SEER		6,1	6,1	6,1	6,1
SCOP		4	4	4	4
Rated cooling capacity	kW	3,52	5,28	7,03	10,55	14	16
Rated heating capacity	kW	3,81	5,6	7,91	11,15	16	17
Dimensions
Dimensions (w x h x d) - OUTDOOR Unit	mm	709 x 536 x 280	785 x 555 x 300	900 x 700 x 350	970 x 805 x 395	940 x 1325 x 370	940 x 1325 x 370
Weight - OUTDOOR Unit	kg	23	29	43	72	92	92
Sound power level - OUTDOOR Unit	dB(A)	64	65	68	66	70	70
Dimensions (w x h x d) -INDOOR unit	mm	700 x 245 x 700	700 x 245 x 700	1000 x 245 x 700	1400 x 245 x 700	1400 x 245 x 700	1400 x 245 x 700
Weight - INDOOR unit	kg	21	22	32	42	42	42
Sound power level - INDOOR unit	dB(A)	54	54	55	55	64	64
