Ventilation systems

BV-PR

Reversible heat recovery ventilation

Residential
Vertical, horizontal

BV-PR is a reversible polypropylene based solution, ideal for new homes where high thermal insulation, low leakage and airtight windows might impede an appropriate and efficient air exchange.


Clean air, hygiene and comfort are essential elements for people's well-being. BV-PR reduces energy consumption both in summer and winter, as the set temperature does not vary and the heat of the expelled air is recovered.

Characteristics


  • Models: 100, 180, 200, 350
  • Reversible horizontal false ceiling or vertical wall installation
  • False ceiling distribution
  • Made of polypropylene, lightweight (13 or 19 kg) and easy to install
  • Compact dimensions
  • Free-cooling as standard

Technical Specification

MODELS100180200350
Technical Data
Nominal air flowm³/h100180200350
Efficiency of heat recovery%90878585
DHW capacityl
Class SEC (3)AAAA
Maximum absorbed powerW113125136179
Maximum absorbed current (1)A0,510,5511,5
Sound power level Lwa (2)dB(A)43455050
Weightkg13131920

(1) Maximum value, including 2 fans and electronics.
(2) Sound power level considering ducted units
(3) Class A+ advanced control including temperature sensor and CO sensor or with advanced control including temperature and humidity sensors

Product Documents

Leaflet
